Optical microscope iScope series

metallurgicaluprightSiedentopf type

Microscopes for materials science applications have the specific objectives and other tools like incident illuminations, polarization and compensation filters. This allows precise observation of materials like metals, plastics, minerals, asbestos, glass, wood and chemical materials. Euromex offers a range of metallurgical microscopes, microscopes with rotatable stages and stain-free objectives for polarized light observation, microscopes for asbestos identification and inverted materials science microscopes  iScope for polarization The iScope microscope are supplied with specific attachments that turn the iScope into a state-of-the art material science microscope suitable for various applications. There are three types of materials science microscopes; Metallurgical and polarization microscopes and microscopes specially for asbestos indentification Highlights • EWF 10x/20 mm and EWF 10x/22 mm eyepieces • Reversed quadruple revolving nosepiece • Ø 160 mm rotatable round stage • iCare sensor for energy saving • Binocular and trinocular models • Plan strain free infinity corrected objectives • Epi-illumination 50 W • CSS - Cable Storage System EYEPIECES All polarization models are supplied with a pair of EWF 10x/20 mm or 10x/22 mm (Ø 30 mm tube) eyepieces, one eyepiece with crosshairs and one eyepiece with crosshairs and micrometer reticle HEAD • Binocular and trinocular Siedentopf type heads with 30° inclined tubes. Interpupillary distance from 48 to 76 mm • Two ± 5 diopter adjustments • A unique rotating system allows the ergonomical positioning of both tubes in a high (431 mm) and in a low position (397 mm) • The trinocular head has a 23.2 mm photo tube.
