Automatic screen printing machine EP1220

solder pasteSMT

The EP1220 handles boards up to 48″ (1220mm) long and 20″ (508mm) wide, ideal for LED lighting applications. The long board printer delivers print accuracy to 12.5µm at 6-sigma and use four fiducials to optimise alignment, paralleling the repeatability performance of our EP700 series platforms. The EP1220 long board screen printer handles boards up to 48″ (1220mm) long and 20″ (508mm) wide, ideal for LED lighting applications. The screen printer has an accuracy of 12.5µm at 6-sigma and uses four fiducials to optimise alignment across the large board area – a factor that becomes increasingly critical with long PCBs. The machine also features in-built Solder Paste Inspection (SPI) technology for added process reassurance. Features/ Benefits: - Cycle times of 14 seconds - Board length up to 48″ - Closed loop squeegee pressure control - Inventive X-axis under stencil cleaning: wet/dry/vacuum - 2-minute product changeover time - 5-minute new product set up time
