U-shaped seal TTS series
lippedcircularpolyurethane

U-shaped seal
U-shaped seal
U-shaped seal
Add to favorites
Compare this product


Characteristics

Type
lipped
Configuration
circular, U-shaped
Material
polyurethane
Application
for cylinders, for hydraulic applications, rod
Fluid
oil
Other characteristics
hydraulic, single-acting, flexible, abrasion-resistant, anti-extrusion
Temperature limit

Max.: 110 °C
(230 °F)

Min.: -30 °C
(-22 °F)

Pressure limit

400 bar
(5,801.5 psi)

Diameter

Max.: 197 mm
(7.756 in)

Min.: 10 mm
(0.394 in)

Outer diameter

Max.: 209 mm
(8.228 in)

Min.: 16 mm
(0.63 in)

Speed

0.5 m/s
(1.6 ft/s)

Description

Profile : TTS U rod seals - Single acting Type : HYDRAULIC SEAL Material : PU Pressure : 40 MPa/400 bar Temperature range : -30°C/+110°C Speed : 0.5 m/s - Excellent sealing at low pressure - Excellent sliding coefficient - Good resistance to extrusion and abrasion

Catalogs

No catalogs are available for this product.

See all of EVCO‘s catalogs
