Ice flaker FIM 60

•Structure: completely realized in stainless steel 18/10 AISI 304. Inside,the structure it includes a bin, realized in atoxic plastic material, whereis stored the ice, when this bin is full, the machine stop itself to produceice. The bin is also insulated, to avoid the melting of the ice stored • Feet: Nr 4 made in plastic material, adjustable in height for levelling • Door: in the front part of the appliance is located the door plastic madethat closes the storage bin • Water inlet and outlet: both located in the rear part of the appliance.The water inlet is 3/4” size, while the water outlet is 24 mm Ø. Both thepipes for the water inlet and outlet are included in the machine, the onefor the inlet is about 100 cm long, while the outlet is about 50 cm • Kind of ice: flake • Production (Kg/24h): 60 • Bin capacity (Kg): 10 • Cooling unit: bottom mounted, with the condensing unit compoundedby Nr 1 hermetic compressor and Nr 1 finned condenser, air cooledthrough a fan, in the version “A” or Nr 1 condenser, water cooled, in theversion “W”. Also, the motor compartment, incorporates the specialevaporator with the screw with no end that crush the ice once formed,and automatically release it into the storage bin. All the mountedcomponents are industrial grade to grant the maximum reliability • Water consumption (litres/Kg): 1 (version A), 5,3 (version W)
