Color LCD signature pad Sig Activ series

5"

Evolis Sig Activ is an high-resolution full color display signature pad with aninnovative sensor surface made of special toughened glass.Thanks to Electromagnetic Resonance Technology (ERT) it is suitable foron-screen handwriting and only responsive to the ERT Stylus. GENERAL FEATURES • Slim and ergonomic design • Active and battery-free pen with changeable pen tips • Tether • 2 LED status indicators DISPLAY • 5’’ (12.7 cm) • Full color TFT • Real time signature display • Backlit display • 16 milions colors • 800 x 480 pixels SENSOR • Electromagnetic Resonance Technology (ERT) • Only responsive to the pen • Active signing area: 108 x 64 mm (4.25’’ x 2.52’’) • Resolution: 10206 x 7422 pixels / 2400 x 2909 ppi • Linearity: +/- 0.4 mm • 1024 pressure levels • Hardened special glass SIGNATURE DIGITIZATION • External sampling rate: 500 Hz (samples per second), 4 axes (x, y, time and pressure) • Internal sampling rate: 6000 Hz (samples per second) SECURITY • AES encryption of data transfer between the pad and the computer • RSA signature and encryption in the pad • Unique internal serial number SIZE AND WEIGHT • 12 x 145 x 177 (0.47’’ x 5.71’’ x 6.97’’) • 220 g (0.49 lbs.) INTERFACE • Windows® USB High-speed (460 Mbits/s) and HID-USB 2.0 High Speed (12 Mbits/s). • Driver necessary for operating system below than W8 available on www.evolis.com POWER • Via USB cable, no external power supply
