Special Features:
Fanless, Low Power
Applications:
Factory e-automation、Home Automation、Digital Signage、Gaming
Function Items - Specifications
Processor - AMD G-Serial T16R
Operating Freq. (Hz) - 1GHz Max
Chipset - AMD Fusion controller hub A55E
BUS I/F - PC/104
L2 Cache - 512KB Per core
On-Board DRAM - -
DRAM Socket - 204-Pin SoDIMM *1 (DDR3L, 4GB Max)
VGA Chipset - AMD T16R(AMD Radeon HD 6250)
VRAM - UMA 384MB Max
Display - VGA、LVDS
Dual Display - Yes
Audio - Yes (Option)
Serial Port - RS232 *1、RS232/422/485 *1
Parallel Port - -
SATA - SATA*1
KB / Mouse - Yes
LAN - 1 (Giga LAN)
USB - 3 (2.0)
GPIO - -
WDT / HWM - Yes / No
Flash/Memory Socket - CFast Socket *1
BIOS - AMI
Power Required - +5V Only, 20VA Max
Operation System - Windows XPe / 7 / 8 / 8.1 / 10 and Linux
Operation Temperature - 0°C to 50°C (32℉ to 122℉)
Compliances - RoHS
Dimension - 102 x 96 mm
