Self-aligning pad TBU-0755

The replaceable pad swivels to allow for self-alignment on uneven surfaces. The replaceable pad fits in a hardened (Rc 58/60) 440c stainless ball cup and is held in place with a lock screw. The pad can be replaced when worn or a different style pad is required. The housing is made from alloy steel, heat treated to Rc 43/46 with black oxide finish. The parts below are for the Swivot assembly only and do not include a pad. Pads must be ordered separately by selecting any fixed gripper or rest pad with the proper diameter. Thread External: 3/4-10 Length Thread: 1 in. Hex Internal - Flat: 3/8 in. Swivel : 20 Degrees. Standoff : 1/8 in. Standoff : 1/4 in. Diameter Ball: 1/2 in. Diameter Replaceable Pad: 3/8 in. Load Rating: 8,150 lbs
