Self-aligning pad MTBU-12025-F

Self-aligning pad - MTBU-12025-F - Fairlane Products
Self-aligning pad - MTBU-12025-F - Fairlane Products
Self-aligning pad - MTBU-12025-F - Fairlane Products - image - 2
Self-aligning pad - MTBU-12025-F - Fairlane Products - image - 3
Self-aligning pad - MTBU-12025-F - Fairlane Products - image - 4
Self-aligning pad - MTBU-12025-F - Fairlane Products - image - 5
Self-aligning pad - MTBU-12025-F - Fairlane Products - image - 6
Self-aligning pad - MTBU-12025-F - Fairlane Products - image - 7
Self-aligning pad - MTBU-12025-F - Fairlane Products - image - 8
Add to favorites
Compare this product

Go to the Fairlane Products website for more information

Description

The replaceable flat ball swivels to allow for self-alignment on uneven surfaces. A Viton O-ring holds the ball in place while keeping contaminants out and providing smooth ball movement. The housing is made from alloy steel, heat treated to Rc 43/46 with black oxide finish. The replaceable ball is made from M-2 high speed steel heat treated to Rc 60/62. Replacement balls and O-rings can be ordered separately Thread External: M12x1.75 Length Thread: 25 mm. Diameter Contact Surface: 6 mm. Height Standoff: 1.5 mm. Swivel : 28 Degrees. Hex Internal - Flat: 6 mm. Diameter Ball: 7 mm. Part No. Ball Only: MBUB-070-F Rating Load: 3,440 lbs.
