Flatbed trailer DPW 1800

platform3-axlefor straw bales

The tough, practical 18 tonne DPW 1800 three-axle flatbed trailer is a safe, easy way to transport bulky goods. It was designed for round and square bales, but can also be used for all kinds of general haulage, especially in agriculture. The flat platform has the ideal dimensions for transporting Euro-palettes. l-beam châssis frame 318 x 120 x 10 mm, fully galvanized, sprung suspension (parabolic springs), turntable diameter 1000 mm, drawbar with height adjustment, stable extendable underrun protection with integrated lighting, wheel chocks Heavy duty ADR-axIes with 6-stud rims, track 1850 mm, axle load 8200 kg/axle at 25 km/h and 7700 kg/axle at 40 km/h, brake cam 300 x 90 mm Single line Hydraulic brake system without regulator (sélection according to country) Fully galvanized bridge floor made of 3 mm sheet steel with non-slip surface, galvanized hinged front and rear wall with support chains, integrated lashing points for safe transport, mechanically extendable rear plate for+1200 mm loading length
