Globe valve 2600

for steamprocess

Series 2600 ASME NB Certified: Air, Steam & Water European CE Approved Sizes 1″ X 2″ to 20″ X 24″. Actual orifice areas from 0.150 to 176.7 square inches. Pressures from 15 to 6000 psig. Temperature range from -450° F to +1500° F. Steel body and bonnet with stainless steel trim. Optional balanced bellows design isolates working parts and top-works from fouling or corrosive service, and nullifies the effects of back pressure on valve performance. The “D” to “T” orifices meet API Standard 526 covering orifice areas and center-toface dimensions. Super capacity types range from “W” (63.62 sq. in.) to “Z” (176.7 sq. in.) and have a maximum set pressure limit of 300 psig. Optional materials of construction include complete 316 stainless steel, Monel®, and Hastelloy® C. Also available with materials in compliance with NACE standards. Higher temperature models use chrome moly body and bonnet. Optional O-ring elastomer seat available for maximum tightness. Applications: air, steam, gas, vapor, and liquid process applications
