Ceiling loudspeaker AM30T

rugged

Transformer Coupled 25, 70, or 100Vrms 30 watt Omnidirectional swivel mount Constant directivity horn design Type 3R enclosure Federal Signal's AM30T is a transformer-coupled, constant directivity, re-entrant speaker ideal for most public address or paging applications. The constant directivity design provides excellent sound coverage throughout the frequency range of speech. The AM30T is molded from impact resistant, beige acrylic-styrene-acrylonitrile (ASA). The omni-directional swivel mount of this speaker allows the unit to be pointed anywhere within a 360º half-sphere of area. Power handling for the AM30T is 30 watts with transformer taps of 30, 15, 7.5, 3.7 and 1.8. A screwdriver operated power switch is used to select the desired tap. This unit is designed for use in 25, 70, and 100Vrms distributed systems. The driver of the AM30T employs a rugged phenolic diaphragm, a 1.5inch diameter voice coil, and rim centered ferrite magnet structure for long life and durability under extreme operating conditions. A 12inch connecting cable, phased and color coded, is provided for connecting the AM30T.
