Pitch (mm/mil) - 5,50 / 216
Temperature - -45°C...+200°C
Additional definition - M3
Dimensions -
Total length (mm) - 11.5
Projection height (mm) - 8
Tip style diameter (mm) - 2.6
Barrel diameter (mm) - 5
Collar diameter (mm) - 4.1
Press ring diameter (mm) - 4.1
Materials & surfaces -
Tip style - 03
Tip style material - Steel
Tip style plating - Rhodium
Plunger material - Steel
Plunger plating - Rhodium
Barrel material - Bronze
Barrel plating - Gold
Spring material - High-grade steel
Spring plating - Uncoated
