Position indicator OP6

6-digithollow-shaft

This is a 5-digit indicator to adjust and directly read a motion (or an angle) obtained by a drive shaft rotation. Shock-proof self-extinguishing technopolymer case. Shock-proof self-extinguishing technopolymer case. Protection IP64. Max. temperature 80°C. Reading with 18° inclined or frontal view. 5 digits counter (standard red digit indicates decimals; on request 2 red digits for hundredths or 5 black digits). Readings until 99999. OP6T model: 4 digits with Vernier. Digit height: 6 mm. On request special ratios and measures in Inch. OP and OP6T standard shaft hole 20H7, models OP6F25 and OP6TF25 with Ø 25 hole. Other holes smaller than 20 with a reducing bush. As option (c) security dowel Ø 10,5/12 mm. Model IN with inox metallic parts. Colours: orange RAL 2004, black RAL 9005, red RAL 3000, grey RAL 7004. Available attachments: shaft block flange, polycarbonate spacer flange, anodizid aluminium movement knob.
