Linear capping machine
beltautomaticbelt

Linear capping machine - Filamatic - belt / automatic / belt
Linear capping machine - Filamatic - belt / automatic / belt
Add to favorites
Compare this product


Characteristics

Type
linear, belt
Operating mode
automatic
Product applications
belt, wheel, wheel, bottle, wheel
Throughput

200 p/min

Description

•Cap sizes from 24 to 58 mm •Quick changeovers •Fits around existing conveyor •High speed operation •Stainless steel frame The FILAMATIC Automatic Belt Wheel Capping machine is a tool-less capper equipped with six capping spindles for production rates up to 200 cpm. Unlike many other cappers, the FILAMATIC BWC can easily adjust for additional bottle and cap sizes and can accommodate container sizes from ml to gallons. It is capable of handling cap diameters from 0.39″ up to 6″ and container sizes from 0.5″-6.25″ width, 2″-12″ height. The control system features a PLC based HMI touchscreen that handles capper functions from start to finish. The front panel includes clutch controls with gauges to precisely set the torque required for capping. The FILAMATIC Belt Wheel Capper features more applications than other cappers and offers optional extended ranges to accommodate most applications. All FILAMATIC cappers can easily be integrated with other FILAMATIC liquid filling machines and auxiliary equipment.
