Needle dispensing valve SV2000N Series

diaphragmsprayprecision

SV2000N Adjustable No-Clog Spray Dispensing Valves The SV2000N series are no-clog spray valves and work best with low-viscosity materials, typically less than 1000cps. Material is typically fed to the spray valve from a pressure reservoir. Each valve is actuated by air pressure sequenced by a controller. The operating air pressure opens a needle valve allowing material to flow, while a separate airline creates pressure in the cap, atomizing the fluid. Valve selection based on required spray area. This spray valve is used in conjunction with the SVC100 controller. • Stroke-adjust control • Tunable spray pattern • Adjustable coating and flow rate • Operating Air Pressure : 70 - 100 psi • Atomizing Air Pressure : 1 - 30 psi max • Fluid Viscosity Range : Up to 1,000 cps • Valve Body/Piston : SS • Valve Needle : SS • Valve Diaphragm : UHMW-PE • Valve Seat : PEEK • Fluid Pressure : 1 - 100 psi • Operating Frequency : Up to 400 cycles / min • Spray Angle : SV2001N: 20° SV2002N: 30° SV2003N: 37° • Operating/Atomizing Air Inlet : 10 - 32 • Material Inlet : 1/8” NPT • Weight : 236 g
