Wine press Jolly 10

“Jolly 10” horizontal press Motorised membrane press made of AISI 304 stainless steel on wheels. Membrane presses in the JOLLY series use the popular membrane pressing procedure in a simple, efficient and economical way. A central elastic membrane, inflated with air, compresses the grapes against the walls of the cylindrical tank. The must is thus completely extracted from the fruit. All processing steps are carried out by the operator with the aid of a gear motor to turn the drum. These steps include loading the grapes, pressing, collecting the must and unloading the marc. An external compressor is therefore needed to inflate and deflate the membrane (Optional). “Jolly 10” horizontal press – Partially perforated tank capacity 10 Hl in AISI 304 stainless steel. – Tank rotation system through variable speed motor drive. – Central elastic membrane in non-toxic food-grade rubber with operating pressures up to 1 bar, which is much lower than other pressing systems, therefore increasing the quality of the extracted must. – Loading and unloading door with manual opening, positioned in the centre. – Collection basin for the outflow must be in AISI 304 stainless steel with quick coupling and decoupling. – Quick compressed air coupling for use with an external air compressor. (Compressor optional). – Pressure gauge to measure operating pressure. – Membrane pressure and vacuum valves. – Safety valve calibrated at 1.5 bar.
