Diaphragm valve CYCLE GARD® I C152Efor controlthreadedpump
Add to favorites
Compare this product
Characteristics
- Type
- diaphragm
- Function
- for control
- Body
- threaded
- Applications
- pump, for water
- DN
Min.: 15 mm
(0.591 in)Max.: 50 mm
(1.969 in)- Pressure
400 psi
- Temperature
80 °C
(176 °F)
Description
Size(s): 1/2 to 2 in. (15 to 50 mm)
Description:
DIRECT ACTING CONSTANT PRESSURE PUMP
CONTROL VALVE - Reduces rapid pump cycling and maintains a pre-set operating pressure for wells. Threaded female x female connection. Features a low lead alloy body & composite bell housing, Nylon reinforced Buna-N diaphragm. Supplied with two FNPT tailpiece and union nuts.
Temp Max: 180°F (80°C)
Pressure Max: 400 PSI
Factory set at 50 PSI
Constant Pressure Pump Control Valves
Flomatic manufactures Constant Pressure Pump Control Valves that provide proven pump cycling protection for water well systems, irrigation and booster systems. The Cycle Gard® I is designed to stop rapid pump cycling, save electricity, eliminate water hammer while providing a constant pressure regardless of water flow.
Catalogs
No catalogs are available for this product.
See all of Flomatic‘s catalogs
