Substrate Multiline TRL Cal
Add to favorites
Compare this product
Description
Millimeter- and submillimeter-wave calibration substrates, optimized for T-Wave™ probes. The multiline TRL calibration substrates offer CPW standards including reflect (short), thru and two lines and are recommended to use with WinCal XE™ calibration software. Some off-set short and off-set open structures are included for additional measurements.
• Substrate material: High-resistivity silicon
• Substrate thickness: 275 µm
• Dielectric constant: 11.8
• Nominal Z0: 50 Ω
