CNC boring machine MZ8B
horizontalverticalfor drilling

CNC boring machine - MZ8B - Foshan Shunde Jiansheng Machine Manufacturing Co., Ltd. - horizontal / vertical / for drilling
CNC boring machine - MZ8B - Foshan Shunde Jiansheng Machine Manufacturing Co., Ltd. - horizontal / vertical / for drilling
CNC boring machine - MZ8B - Foshan Shunde Jiansheng Machine Manufacturing Co., Ltd. - horizontal / vertical / for drilling - image - 2
Add to favorites
Compare this product


Characteristics

Control type
CNC
Spindle orientation
horizontal, vertical
Applications
for drilling, for wood
Spindle diameter

Min.: 0 mm
(0 in)

Max.: 35 mm
(1 in)

Power

31.9 kW
(43.37191 hp)

Description

Woodworking eight lines CNC boring machine Workpiece width : 100-1000mm Workpiece length : 250-2440mm Workpiece thickness : 10-40mm Vertical spindles number : 11*12=132 Horizontal spindles number : 22*2=44 Vertical drilling speed : 5-36m/min Horizontal drilling speed : 5-36m/min Drill bit handle diameter : 35mm Max drill bit diameter : 35mm Max drill bit length : 57mm/70mm Voltage : 380V/50Hz Total power : 31.9kw Air pressure : 0.6mpa Weight : 3400kg Dimension : 5000*1950*1650mm
