Diesel engine CURSOR 16
6-cylinderturbochargedmarine

Diesel engine - CURSOR 16  - FPT Industrial S.p.A. - 6-cylinder / turbocharged / marine
Diesel engine - CURSOR 16  - FPT Industrial S.p.A. - 6-cylinder / turbocharged / marine
Diesel engine - CURSOR 16  - FPT Industrial S.p.A. - 6-cylinder / turbocharged / marine - image - 2
Diesel engine - CURSOR 16  - FPT Industrial S.p.A. - 6-cylinder / turbocharged / marine - image - 3
Diesel engine - CURSOR 16  - FPT Industrial S.p.A. - 6-cylinder / turbocharged / marine - image - 4
Diesel engine - CURSOR 16  - FPT Industrial S.p.A. - 6-cylinder / turbocharged / marine - image - 5
Diesel engine - CURSOR 16  - FPT Industrial S.p.A. - 6-cylinder / turbocharged / marine - image - 6
Diesel engine - CURSOR 16  - FPT Industrial S.p.A. - 6-cylinder / turbocharged / marine - image - 7
Add to favorites
Compare this product


Characteristics

Type
diesel
Number of cylinders
6-cylinder
Technology
turbocharged
Product applications
marine
Emissions level
Tier 2, Tier 3
Power

Max.: 735 kW
(999.322 hp)

Min.: 368 kW
(500.341 hp)

Torque

3,510 Nm
(2,588.8431 ft.lb)

Rotational speed

1,800 rpm, 2,300 rpm
(11,309.73 rad.min-1, 14,451.33 rad.min-1)

Displacement

15.9 l
(4.2 gal)

Weight

1,570 kg
(3,461.26 lb)

Length

1,465 mm
(57.7 in)

Width

1,000 mm
(39.4 in)

Height

1,160 mm
(45.7 in)

Description

High power density with minimum fuel consumption and emissions structural stiffness / low vibration and noise Up to 600 hours service intervals Cursor engines offer outstanding power output standards with minimum displacement and the highest levels of reliability. Professionals of the sea trust Cursor engines for their high innovation level, easy maintenance and extreme efficiency – that result in competitive operating costs. Cursor versions for pleasure applications ensure simple installation, excellent performance, quietness and reliability. They are recommended for yachts and sport-fishing boats up to 18 meters (according to boat displacement). The Cursor Series is offered in high-performance, light-, medium- and heavy-duty versions. All engines can be customized on request. Options include electronic remote control, monitoring systems and compliance to international emission standards as​ IMO MARPOL, EU-RCD, EU-IWV, USA-EPA Recreational & Commercial and RINA propulsion homologation.​ High power and torque density levels come together with low fuel consumption and contained environmental impact. Lay-out and specific settings are focused on marine duties. Both engine and turbocharging cooling systems are specifically optimized for the mission. In order to make installation easier (and prevent leakage), the oil cooler, oil pump, water pump and blow-by system have been integrated into the engine design. Cursor state-of-the-art technologies guarantee high injection pressure and adamant timing precision under any operating condition. This translates into rapid response at all engine speeds.
