Hydraulic vacuum filler F-LINE F193 series

continuoushigh-speedfor sausages

Fully electronic, continuous vacuum stuffer for STRAIGHT FILLING, PORTIONING and LINKING with removable ADG04 linking gear and Top-Line drive. • Filling capacity up to approx. 3,000 kg/h • Machine housing and hopper made entirely of stainless steel • Hopper approx. 300 liters • Optional: Divisible hopper approx. 40/300 liters possible • Filling pressure up to max. approx. 55 bar • Digitally-controlled vacuum system • Electrically locked step • Vacuum pump 21 m³/h • Total connected load 10.5 kW • Rotary current 400 Volt, 50 Hz • Including standard accessories and accessory holder • FREY TC 733 touch control • Industrial PC control • 12 inch TFT color display, resolution 800 x 600 pixels • Screen size 247 x 185 mm • Self-explanatory operation via touch-sensitive, robust film on the (touch)display • Ethernet interface, allows remote control and remote maintenance • USB interface for easy data transfer • CAN bus for high-speed communication with attachments • Table of contents and product name shown in the program • Portioning range 5 - 100,000 g (5 - 999 g in 0.1 g increments) • Speed and pause lengths are infinitely variable • Flow measurement, piece counter, count-based auto stop • Flow-reverse mechanism and adjustable 1st portion weight • Error display • Memory for 200 filling programs, incl. cooked sausage programs • Electronic pulse control for clipping machines • Attachment control • Multilingual The F-LINE F193 SA is equipped with a high-speed servo linker. This ensures the highest linking precision and speed. The servo linker is used as a drive for the optional WK98 grinding head system.
