Diesel generator set CHAIWEI

three-phasestationaryair-cooled

Genset use the integrated structure. base frame with high-strength steel Genset connected with full suspension shock absorber design, good damping effect and small shake. Diesel choice of Shanghai jiading or Shanghai Niuhe diesel. 12V/24V DC electric start. with tank water cycling and Fan cooling. Generator choice of MINDONG self-produced generator. STC series third harmonic generator; TFW2/TFW3 AVRAutomatic Voltage Regulator . class H insulation. protection class according to IP21/22 standard Control panel: standard configure Backpack switch box creen liquid crystal display {LCD)-specific control module controls. have automatic start. data acquisition and display, fault alarm and protection functions ,configuration of electric monitoring instrument and diesel operation instrument, Genset have generator and engine operation monitoring instrumentation. with MCCB circuit breakers. with short circuit, overload protection function . Gensat output power to meet the following environmental conditions:≤1000m Ambient temperature:≤40°C。 2、Genset with 12V high-performance lead-acid batteries and charging generator, can be six consecutive start。 3、Genset equipped with the base daily tank, to meet the unit more than 6 hours of continuous full load。 4、Genset attach muffler. corrugated absorber and simple installation materials. configure the base shock absorber。 5、Warranty period: from the date of out of warehouse for one year or l000 hours. 6、Genset selectable configuration includes the following. Self starting control module Remote monitor module Automatically load the output of the cabinet. the ATS automatically switch cabinet and the AMF mains voltage
