Wall fan UF9439 SERIES
mixed-flowcoolingsteel

Wall fan - UF9439 SERIES - Fulltech Electric CO., LTD. - mixed-flow / cooling / steel

Add to favorites

Compare this product

Characteristics

Type: wall
Configuration: mixed-flow
Function: cooling
Material: steel, plastic
Air flow: 7.5 m³/min, 9 m³/min
(264.86 ft³/min, 317.832 ft³/min)

Description

Frame: - Steel with black painting Impeller: - Plastic & Aluminum Bearing System: - Ball bearing or sleeve bearing Motor: - Capacitor start-run or Shaded pole Protection: - Impedance-Protected or Thermally-Protected Insulation Resistance: - Above 100MΩ,DC 500V. Dielectric Withstand Voltage - AC1, 500V (50/60Hz) one minute Safety Approval: - CE, TUV. (UF9029 has UL, CUL approval) Rated Voltage - 120 V - 230 V - Frequency - 50/60 Hz - 50/60 Hz - Input Power - 43/50 W - 43/50 W - Rated Current - 0.4/0.4 A - 0.2/0.22 A - Locked Current - 0.6/0.6 A - 0.31/0.31 A - Speed - 1400/1600 RPM - 1400/1600 RPM - Maximum Air Flow - 7.5/9 m3/min. - 7.5/9 m3/min. - Maximum Air Flow - 265/318 CFM - 265/318 CFM - Maximum Pressure - 3.5/4.5 mmH2O - 3.5/4.5 mmH2O - Maximum Pressure - 0.14/0.18 InchH2O - 0.14/0.18 InchH2O - Noise - 48/53 dB - 48/53 dB - Weights - 3.5 kg - 3.5 kg
