Analog I O module Q.bloxx A106

2-Iconfigurable

2 galvanically isolated analog inputs channels strain gage and inductive half and full bridges, LVDT, RVDT quarter bridge with completion terminal DC and carrier frequency (CF) principle 2.5 and 5 VDC excitation, 2.5 and 5 VDCeff excitation carrier frequency, 600 Hz or 4.8 kHz configurable per channel 2 Analog output channels ±10 VDC, 10 kHz update rate per channel High-accuracy digitization 24-bit ADC, 10 kHz sample rate per channel 4 digital I/Os input: state, tare, memory reset, output: state, alarm, threshold Signal conditioning linearization, filtering, average, scaling, min/max, RMS, arithmetic, alarm 3-Way galvanic isolation Channel to channel, channel to power supply, and channel to bus
