Gas filter G10Fbasketcartridgepressure
Add to favorites
Compare this product
Characteristics
- Designed for
- gas
- Filtration element
- cartridge, basket
- Filtration method
- pressure
- Applications
- industrial, high-pressure
- Material
- stainless steel, brass, iron
- Mounting
- threaded
- Fluid specification
- for LPG
- Other characteristics
- compact
- Operating pressure
Max.: 600 bar
(8,702.264 psi)Min.: 10 bar
(145.038 psi)- Filtration size
1 in
- Fluid temperature
Max.: 60 °C
(140 °F)Min.: -20 °C
(-4 °F)
Description
The filter with over pressure slam shut incorporated has focus on residential and commercial natural gas and LPG applications and industrial and commercial LPG applications. The slam shut incorporated is totally buble tight and with easy reset after trigged.
It has a simple and unique design with target of less space required becoming the installation more compact than the standard ones. It can be installed in any position wituout affect the operation or reset after emergencial trigged. This equipments foresees the installation of cartridge (for Natural Gas) or basket (for LPG) filter element with simple change of flow direction.
It has CE Stamp.
Materials:
Seals: Buna N
Filter Element: Pleated Celullose Fiber or S.S. Basket
Filtration Degree: 5 to 20 micra
Connections:
Thread NPT or BSP
