Rotary vane vacuum pump 1550 series

lubricatedsingle-stagefor laboratories

Power 3/4 hp ( 0.56 kW ) Max Flow (50 Hz) 11.5 cfm ( 19.5 m3/h ) Max Flow (60 Hz) 14.5 cfm ( 24.7 m3/h ) Max Pressure (50 Hz) 15 psi ( 1 bar ) Max Pressure (60 Hz) 15 psi ( 1.0 bar ) Max Vacuum (60 Hz) 20.0 in-Hg ( 335.0 mbar abs ) Weight 33 lbs ( 15 kg ) Min Temperature 33.8 °F ( 1 °C ) Max Temperature 104 °F ( 40 °C ) Product Details The easy to install, rugged 1550 Series offers oil-less operation to ensure the discharge air remains free of contamination from lubricants. They produce minimal noise or vibrations, which makes them well suited for noise sensitive environments like medical, dental and laboratory applications. In addition, these compact units offer high flow, pulse free air– making them ideal for applications requiring consistent air pressure and air flow. Low Maintenance Vanes and filters are easily serviceable to extend the life of the product and maximize uptime. Pulley Driven The pulley driven system allows for multiple operating speeds. Separate Drive The separate drive allows customer to select the motor technology (AC, DC, BLDC) that best suits their needs and application. Variable speed motors can be used to control the amount of air flow. Includes Includes Filter, Cooling Fan, Pulley and Muffler. (vacuum models)
