Chemical product hose GSI® 75 NTfoodstuffsiliconehigh-temperature
Add to favorites
Compare this product
Characteristics
- Use
- for chemical products, foodstuff
- Material
- silicone
- Applications
- high-temperature, for chemical applications, for the food industry, for the pharmaceutical industry, for the cosmetic industry
- Norms
- DIN
- Other characteristics
- flexible, standard, vacuum, rugged, extruded, reinforced, corrosion-resistant
- Inner diameter
Max.: 102 mm
(4.016 in)Min.: 8 mm
(0.315 in)- Outer diameter
Max.: 118 mm
(4.646 in)Min.: 17.5 mm
(0.689 in)- Pressure
Max.: 20 bar
(290.075 psi)Min.: 6 bar
(87.023 psi)- Temperature
Max.: 180 °C
(356 °F)Min.: -60 °C
(-76 °F)- Delivered length
5.7 m
(18'08" )
Description
Fully extruded silicone, textile reinforcements and HR* stainless steel wiring. NT version white platinum cured. NTP version natural platinum cured.
Product highlights
Autoclavable hose
High working temperature
Good vacuum capability
High flexibility and robustness
NT model
Recommended for food and pharmaceutical applications
NTP model
Recommended for food, pharmaceutical and biotechnology applications
Cytotoxicity, Haemolysis, European Pharmacopoeia
*HR : high resistance against under stress corrosion
Assembling possibilities
316L stainless steel swaged fittings are monoblocs (without welding) in accordance with the NRS® design (Non Retention System). The hose can be also supplied with the reusable MSP® fitting (up to ND51). All kinds of fittings available on request (SMS, DIN, CLAMP, RJT, ISS, FIL, GAS, NPT, JIC, FLANGES, etc).
