Galvanised steel grating Louvred

sheet metalfor vertical screen printing framesfor bearings

Louvred GEI gratings are used for façades to provide a visual screen, a brise-soleil effect or a privacy screen, as well as to form a wall that counteracts any impressions of emptiness. Louvred GEI grating is manufactured according to a precise load table. The dimensions of the bearing bars (BB) are important because they determine the load bearing capacity of the grating. These are decided based on standards and load capacity. For louvred grating, mesh centre distances for the BB and TB are typically in multiples of 11.11. G.E.I has a range of louvred gratings with different mesh available: 100 x 30 - 60 x 30 - 30 x 30. Other options are available on request. Maximum dimensions: 2,500 x 2,000 mm. For optimal grating quality, we advise you not to exceed a height/length ratio of 1.5 m2. S235JR steel as per EN 10025 standards. 304 (1.4301) or 316Ti (1.4571) stainless steel. AlMg3 aluminium. Fastening systems are manufactured from galvanised steel for steel gratings and from stainless steel for stainless steel and aluminium gratings. In certain cases, gratings may be fixed to structures with welded brackets.
