Technical Data / Performance Data
• Slurry density : max. 1200 kg/m3
• Mixing components : 2 1 x liquid / 1 x solid
• Solids grain size : max. 1 mm
• Dosage liquids : manual hand control valve
• Dosage solids : electrical rotary valve with adjustable speed
• Dosing capacity solids 2) : 500 - 2500 kg/h 2)
• Mixer outlet : Storz B 3“ standard coupling DIN 14307, alternatively 3“ IG
• connection : Storz C 2“ standard coupling DIN14307, max. 6 bar; alternatively 2” IG
• Power connection : CEE-plug 63 A, 5-pole
• Power input : 27 kW
• Voltage : 400 V; 50 Hz
• Dimensions : 3,0 x 2,44 x 2,59 m ( L x W x H)
Application areas:
• Tunnelling
• Special foundation engineering
• Shield tunnelling
• Hydro shield operation
• Diaphragm wall
• Cut-off wall
Mixing of:
• Bentonite slurries
• Cut-off wall components
