Technical Data / Performance Data
• Suction lift max. 8 m
• Solids grain size max. 24 mm
• Suction connection Storz B 3“ standard coupling DIN 14307, alternatively 3“ AG, flange DN80 PN16
• Pressure connection Storz B 3“ standard coupling DIN 14307, alternatively 3“ AG, flange DN80 PN16
• Power connection CEE-plug 32 A, 5-pole
• Voltage 400 V; 50 Hz
Application areas:
• Building construction and Civil engineering
• Special foundation engineering, Tunnelling
Pumping of:
• Light mortar
• Foam concrete
• Slurries
• Dirty water or other solid-containing slurries
Characteristics:
• dry running
• self-priming
• reversible
• flow rate continuously adjustable
• high productivity
• high operating reliability
• easy wear compensation of the hose pump via easy eccentric adjustment
• central lifting eye for crane handling
• forklift and lift truck handling from long side
