Signal amplifier ZS / CAM-90electronicmodularfiber optic
Add to favorites
Compare this product
Characteristics
- Type
- signal
- Other characteristics
- electronic, modular, fiber optic
- Voltage
12 V
- Current
35 mA
Description
Twisted-pair transmitter in miniature housing with angular BNC-plug for direct connection to any video camera.
Applicable for colour or monochrome signals.
Transmission distance under optimal conditions max. 1200 m with 0.6 mm^2 twisted pair cable.
1 x BNC video input, 1 twisted pair output
Bandwidth: 20 MHz / - 0,3 dB
50 MHz / - 2 dB sowie 60 MHz / - 3 dB
Output level (twisted-pair): max. 2.5 Vpp
Frequency boost @ 5 MHz: 0 dB +/- 0.2 dB
Power supply: 12 VDC / 35 mA
Dimensions in mm (W x H x D): 56 x 29 x 55
Weight: approx. 50 g
In miniature housing (can be plugged directly onto camaera BNC-output) (ZS/CAM-90)
Very high bandwidth of 60 Mhz (- 3 dB)
Comfortable mounting
Overvoltage protection
Small size
