Pico-ITX motherboard PICO-G350A

Arm® Cortex®-A53 Quad-coreIntel®LPDDR4

PICO-ITX with Arm® Quad-Core Cortex®-A53, Onboard LPDDR4X, eMMC 8GB, 4 x USB 2.0, 1 x USB OTG Specification Form Factor - PICO ITX 100W x 72D (mm) CPU - MT8365 Arm® Quad-Core Cortex®-A53 up to 2.0GHz Socket - FCBGA Memory - LPDDR4X 4GB (on board) Ethernet - Integrated 100M Ethernet Video - Integrated Graphics Processor – Mali-G52: 1 x HDMI port - For Android : supporting a maximum resolution of 1280x720 @60Hz For Yocto : supporting a maximum resolution of 1920x1080 @60Hz 1 x LVDS port, supporting a maximum resolution of 1366x768 @24bit or 18bit (Optional) 1 x MIPI-DSI (Optional) Audio - Integrated - Audio codec and amplifier Storage - eMMC 8GB (on board) Expansion Slots - 1 x 2230 M.2 E-Key, support AW-CB451NF-D (IEEE 802.11a/b/g/n/ac Wireless LAN 2T2R and Bluetooth 5.1 Combo Module) Internal I/O - 1 x Front panel header 1 x Front audio header 1 x Speaker header (2W/4ohm) 2 x UART 2 x USB 2.0 headers (host) 1 x USB 2.0 header (OTG) 1 x GPIO (8 bits) header 1 x MIPI-DSI (optional) 1 x Micro SD Slot Front I/O - 1 x OTG USB (internal micro-USB Connector) Rear I/O - 1 x DC In power jack - System adapter 12~24V 2 x USB 2.0 Ports (Host) 1 x RJ45 LAN Port 1 x HDMI
