Feed hopper: 7 m³
Feed channel: 1200 x 2500 mm
Pre-screen machine: 1200 x 2500 mm
Jaw crusher inlet: 1330 x 850 mm
Crusher capacity: up to 600 t/h
Discharge conveyor: 1400 x 11500 mm
1-deck screen machine: 1500 x 3500 mm
Conveyor below screen: 1000 x 7500 mm
Oversize recirculation conveyor: 650 x 10000 mm
Powerpack: C13 Acert / 354 kW
Transport length: 25000 mm
Transport width: 3800 mm
Transport height: 4200 mm
Weight with screen: 90000 kg, without screen: 80000 kg
