Electrical wire stripping machine GM216

bench-topelectric

The STRIPPING AND TWISTING MACHINE GM216 can STRIPPING and TWISTING CABLE. The STRIPPING AND TWISTING MACHINE GM216 has electrical operation and is a great flexibility machine suitable for STRIPPING and TWISTING with all types of insulator. The STRIPPING AND TWISTING MACHINE GM216 is particularly suitable for those processes that require high speed stripping and twisting of the wires, repeating the stripping on wires of the same section. The machine is supplied complete with instruction manual and CE certifications. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - No ABSORBIMENT - 110 W STRIPPING LENGTH - 1,5÷35 mm WORKABLE SECTIONS - 0,517÷26,5 mm² WORKABLE CABLE - PVC-Teflon-Silicon-Similar MIN CABLE LENGTH - 22 mm + Strip TOLERANCE - <= 0,002 xL (L=Stripping Length) DISPLAY - No MEMORY - No WEIGHT - 7 Kg DIMENSIONS - 150x330x220 mm (WxDxH)
