Enameled wire stripping machine HP35manualportable
Add to favorites
Compare this product
Characteristics
- Product to be stripped
- enameled wire
- Other characteristics
- manual, portable
- Diameter
Max.: 6 mm
(0.24 in)Min.: 0.15 mm
(0.01 in)
Description
The MANUAL STRIPPING MACHINE HP35 FOR ENAMELLED CONDUCTORS has the ability to easily adjust the opening of the brushes by means of micrometric adjustment, making this machine very flexible and fast.
ALIMENTATION - Monophase 230 V 50/60 Hz
PNEUMATIC ALIMENTATION - No
ABSORBIMENT - 110 V
STRIPPING LENGTH - Illimitate
WORKABLE SECTIONS - 0,18÷30 mm²
WORKABLE CABLE - Enamelled Wire
MIN CABLE LENGTH - 30 mm + Strip
TOLERANCE - Not Definabile
DISPLAY - No
MEMORY - No
WEIGHT - 2,4 Kg
DIMENSIONS - 350x130x105 mm (WxDxH)
VIDEO
Catalogs
HP35
1 Pages
