Manual stripping machine HP30cableenameled wireportable
Add to favorites
Compare this product
Characteristics
- Product to be stripped
- cable, enameled wire
- Other characteristics
- manual, portable
- Diameter
Min.: 0.15 mm
(0.01 in)Max.: 3 mm
(0.12 in)
Description
MANUAL STRIPPING MACHINE HP30 FOR ENAMELLED CONDUCTORS with brushes in steel strands suitable for CABLES or COPPER PLATES.
The STRIPPING MACHINE HP30 FOR ENAMELLED CONDUCTORS have the ability to easily adjust both the opening of the brushes by means of micrometric adjustment makes this machine very flexible and fast.
The STRIPPING MACHINE HP30 FOR ENAMELLED CONDUCTORS is suitable for CABLES or PLATES from 0,15 to 3 mm of thickness.
ALIMENTATION - Monophase 230 V 50/60 Hz
PNEUMATIC ALIMENTATION - No
ABSORBIMENT - 110 W
STRIPPING LENGTH - Illimitate
WORKABLE SECTIONS - 0,18÷6,8 mm²
WORKABLE CABLE - Enamelled Wire
MIN CABLE LENGTH - 30 mm + Strip
TOLERANCE - Not Definibile
DISPLAY - No
MEMORY - No
WEIGHT - 2,4 Kg
DIMENSIONS - 350x130x105 mm (WxDxH)
VIDEO
Catalogs
HP30
1 Pages
