Cable cutting and stripping machine TS70

pneumaticwith touch screen

The CUTTING AND STRIPPING MACHINE GM TS70 is electronic and of the latest generation for cables up to 25 mm outside diameter. The peculiarity of the opening of the rollers of the cable stripper CUTTING AND STRIPPING MACHINE GM TS70 (pneumatically) of cable exit during the head stripping phase allows the cable stripper cutter CUTTING AND STRIPPING MACHINE GM TS70 to get to make unlimited stripping with extreme precision and simplicity. The CUTTING AND STRIPPING MACHINE GM TS70 is supplied complete with all accessories, protections and the instruction manual. The CUTTING AND STRIPPING MACHINE GM TS70 is complete with CE certification. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - 6 Bar ABSORBIMENT - 1500 W STRIPPING LENGTH - Front 1÷800 mm – Back 1÷260 mm WORKABLE SECTIONS - 10÷70 mm² - Till to 25 mm CUTTING LENGTH - 20 mm÷100 m FEEDING - 4 Belt Feeding-24 Drive Motors WORKABLE CABLE - PVC-Teflon-Silicon-Glass PRODUCTIVITY - L = 100 mm, 600 – 1.800 pcs/h TOLERANCE - ≤ 0.002xL (L= Cutting Length) DISPLAY - Display LCD Liquid Cristal Display MEMORY - 100 Programs WEIGHT - 260 Kg DIMENSIONS - 1600x760x1350 mm (WxDxH)
