Manual stripping machine D2

cableelectricpneumatic

The MANUAL STRIPPING MACHINE D2 is a manual bench machine used to UNIPOLAR AND MULTIPOLAR CABLES EXTERNAL SHEATHING with a maximum diameter up to 12 mm in a simple and fast way. The operation of the MANUAL STRIPPING MACHINE D2 is simple, after having selected the correct side of the 4-POSITION BLADES for the STRIPPING OF THE CABLE to BE STRIPPED and adjusted the appropriate arm to determine the desired length of STRIPPING, just insert the cable in the appropriate guide and by pulling the lever of the MANUAL STRIPPING MACHINE D2 it is possible to obtain COMPLETE or PARTIAL STRIPPING quickly and easily and without damaging the copper strands or the INTERNAL CONDUCTORS OF THE DRAWN CABLE. The 4-POSITION BLADES allow you to STRIP a wide range of diameters or if necessary quickly it is possible to replace them with another set of 4-POSITION BLADES to vary the range of possible DRAWING diameters. The MANUAL STRIPPING MACHINE D2 must be fixed to a workbench or to a flat surface. The MANUAL STRIPPING MACHINE D2 does not need either an electric or pneumatic power supply for its operation. ALIMENTATION - No PNEUMATIC ALIMENTATION - No ABSORBIMENT - No STRIPPING LENGTH - 3÷170 mm WORKABLE CABLE - PVC-Teflon-Silicon-Similar MIN CABLE LENGTH - 250 mm + Strip TOLERANCE - <= 0,002 xL (L=Stripping Length) DISPLAY - No MEMORY - No WEIGHT - 4 Kg DIMENSIONS - 300x350x110 mm (WxDxH)
