Enameled wire stripping machine D10

cablepneumatic

The STRIPPING MACHINE GM D10 FOR ENAMELLED WIRES is suitable for a perfect removal of the insulating film of every type of ENAMELLED WIRES and FLATS in silk, nylon, paper etc., even if impregnated on the whole circumference of the conductor. The STRIPPING MACHINE GM D10 FOR ENAMELLED WIRES can easily adjust both the peeling length and the opening of the brushes by means of micrometric adjustment which makes this STRIPPING MACHINE machine very flexible and fast. The brushes are made of metal or fiberglass strands and have different degrees of hardness depending on the type and section of the ENAMELLED CONDUCTOR. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - No ABSORBMENT - 300 W STRIPPING LENGTH - 3÷40 mm WORKABLE SECTIONS - 0,032÷13,2 mm² WORKABLE CABLE - Enamelled Wire MIN CABLE ENGTH - 30 mm + Strip TOLERANCE - Not Definable DISPLAY - No MEMORY - No WEIGHT - 25 Kg DIMENSIONS - 550 x 350 x 500 mm (WxDxH)
