Cable crimping machine GM139B

for cable terminalsautomaticpneumatic

The BENCH CRIMPING MACHINE GM139B is a completely pneumatic machine for CRIMPING metal contacts on UNIPOLAR CABLES up to 70 mm2. The BENCH CRIMPING MACHINE GM139B, thanks to the simple and fast interchangeability of the DIE SETS, allows to CRIMP different types of electrical terminals with the possibility of imprinting them with different shapes. The BENCH CRIMPING MACHINE GM139B is supplied with pneumatic pedal and connection tubes between it and the CRIMPING MACHINE. The CRIMPING speed can be adjusted by means of a valve located on the machine side. The GM139B BENCH CRIMPING MACHINE is supplied complete with user manual and CE certification. ALIMENTATION - No PNEUMATIC ALIMENTATION - 6÷8 Bar ABSORBMENT - No WORKABLE SECTIONS - 0,5÷70 mm² STROKE - No WORKABLE TERMINALS - Whatever PRODUCTIVITY - Not Definable DISPLAY - No DIMENSIONS - 286 x 135 x 165 (WxDxH)
