Crimping press P60

pneumaticautomaticelectronic

The POWER CRIMPING PRESS GM P60 is equipped with a parallel locking mechanism, it has been developed to be the most powerful pneumatic press in the GM catalog for the processing of large bulk terminals. The adapter of the POWER CRIMPING PRESS GM P60 can be replaced without the use of tools and guarantees very high levels of flexibility, so as to be able to work on small applications (min.0.08 mm²) and on larger sections (max. 185 mm) . Many standard and special applications are available thanks to the adapters of the POWER CRIMPING PRESS GM P60 you can switch from one CRIMPING DIE to another quickly and easily. Thanks to the integrated regulation of the crimping stroke, the POWER CRIMPING PRESS GM P60 guarantees short cycles with reduced energy consumption. The machine is supplied complete with instruction manual and CE certifications. • High quality, process stability and flexibility • Controlled stroke adjustment • Electronic counter of the pieces, lighting by LED light, safety pedal • Dimensions: 540 x 260 x 515 mm
