Automatic splicing machine GM322

The SPLICING MACHINE GM322 is a machine of extremely compact dimensions and easy to use, it is particularly suitable for performing CABLE-CABLE JOINTS or COMPONENT CABLE JOINTS. The SPLICING MACHINE GM322 uses a brass band or other material wound on a reel available in the sizes of 2, 4 and 6 mm with a thickness from 0.25 to 0.4 mm which is preformed during the CRIMPING process of the wires on which make the JOINT. Thanks to this peculiarity, with the SPLICING MACHINE GM322 it is possible to make joints even in the presence of reduced dimensions. A wide range of interchangeable tools is available according to the type of machining required. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - No CRIMPING FORCE - 2.000 Kg (20.000 N) SPLICE WIDTH - Till to 6 mm SPLICE THICKNESS - 0,25÷0,4 mm WORKABLE MATERIALS - Splice PRODUCTIVITY - 1.000÷3.000 pcs/h DISPLAY - Digital Numerical Viewer WEIGHT - 43 Kg DIMENSIONS - 310x310x370 mm (WxDxH)
