Automatic wire tying machine GM149

The TYING MACHINE GM149 needle binder has been developed specifically to link ring-shaped products with a minimum diameter of the internal core of 35 mm. The TYING MACHINE GM149 needle binder is supplied with the well-known grip and knotting technology, which has been successfully used for many years in other GM series binding models. This TYING MACHINE GM149 needle binder is available in many sectors, for example for the cables industry and in the automotive industry. • Diameter of the inner core of the packages, of only 35 mm • Extremely easy operation • Robust, resistant and very reliable • Minimum maintenance • Available in automatic and fully automatic versions • Up to 75 cycles per minute ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - No ABSORBMENT - 400 W BINDING DEPTH - 150÷250 mm, Diameter min. 35 mm MATERIAL DIAMETER TO BE BINDED - Min 35 mm START - Pedal CONSUMABLE MATERIAL - Till to 110 N, PSc 1300, 2K, 3 K WORKABLE MATERIAL - Used in many sectors PRODUCTIVITY - Till to 75 Cycle/m DISPLAY - No MEMORY - No WEIGHT - 75 Kg DIMENSIONS - 1020x557x402 mm (DxWxH)
