Electric thermo-shrinking machine H38

desk

The HEATING MACHINE FOR SHRINK H38 allows in a simple and fast way the retraction of the thermal sheath on the wire, the heat emitted by the infrared radiant tube capable of reaching a temperature up to 180 ° C. The HEATING MACHINE FOR SHRINK H38 has a static operation, it is possible to insert the end of the cable inside the oven or only the central part of the cable by letting the ends come out from the sides. The HEATING MACHINE FOR SHRINK H38 is supplied complete with instruction manual and CE certifications. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - No ABSORBMENT - 1900 W OVEN TEMPERATURE - 180°C HEATING METHODOLOGY - Infrared Radiant Tube WORKABLE DIAMETER - Max 38 mm SHRINK LENGTH - Max 78 mm FEEDING - No DISPLAY - Digital Numeric Viewer MEMORY - No WEIGHT - 14 Kg CONTROLLER DIMENSIONS - 195x195x140 mm (DxWxH) OVEN DIMENSIONS - 190x260x180 mm (DxWxH)
