Worm gear reducer MRV/RV 2U seriesright angledual-shaft500 - 1000 Nm
Add to favorites
Compare this product
Characteristics
- Type
- worm
- Shaft orientation
- right angle
- Shaft configuration
- dual-shaft
- Torque
- 500 - 1000 Nm
- Applications
- industrial
- Rotational speed
750 rpm, 1,000 rpm, 1,500 rpm
(4,712.39 rad.min-1, 6,283.19 rad.min-1, 9,424.78 rad.min-1)- Power
Max.: 11 kW
(14.96 hp)Min.: 0.18 kW
(0.24 hp)
Description
Special design for automated plant and systems. Synchronised, counter-rotating output shafts.
Alluminium gear casing.
Motor/motor-variator coupling selected according to service requirements.
P1 0,18 kW...11 kW
Rt 1:7,5...1:100
Mt2 8 Nm...1000 Nm
