Foam-based fire extinguishing system 4 - 10 bar | Prima SmartCAFS200

Prima Series vehicle pump with CAFS - a unit driven directly from the pump pto for compressed air foam fire fighting. Prima P1 or P2, 3010 or 4010, aluminium or bronze models can be used. CAFS unit is a compact package attached to pump rear, comprising a compressor, FoamLogix proportioning unit (3.3, 5.0, 6.5) and mixing manifold. The computer controlled FoamLogix system constantly monitors the water flow to maintain an accurate and reliable foam/water ratio, designed to inject Class B foam between 0.1% and 9.9% range. Foam pump is an electric driven rotary plunger pump with a maximum foam flow rate of 12l/min, 19l/min or 24.6l/min. Compressor is rotary twin screw compressor with air receiver/separator and lubrication system, nominal output of 200scfm at 10 bar. System fitted with Smart switches for selecting wet or dry CAFS - allows discrete performance and preprogrammed positions. This is state-of-the-art technology providing the advanced fire fighting power of compressed air foam - improved knockdown times, reduced water damage and water useage.
