Fiber laser cutting machine P3080
for steelfor stainless steelfor aluminum

fiber laser cutting machine
fiber laser cutting machine
fiber laser cutting machine
Add to favorites
Compare this product


Characteristics

Technology
fiber laser
Material
for steel, for stainless steel, for aluminum, for copper, for brass, for titanium, for iron, for carbon steel
Product handled
tube
Control type
CNC, servo-driven
Associated function
engraving, marking, drilling, hole punch, profiling, multi-function, beveling, trimming
Applications
for industrial applications, for the automotive industry, for metal fabrication, for aeronautical applications, for the electronics industry, for medical applications
Configuration
gantry type, large-format, 3-axis, 5-axis, 6-axis
Other characteristics
high-performance, automatic, high-power, combined, high-precision, mild steel, with conveyor, high-speed, precision, CE, FDA, high-efficiency, SGS, for steel construction
X travel

9,180 mm
(361.42 in)

Y travel

400 mm
(15.75 in)

Tube diameter

Max.: 200 mm
(8 in)

Min.: 20 mm
(1 in)

Laser power

Max.: 4,000 W

2,000 W, 3,000 W

Min.: 700 W

Description

Metal pipe and tube laser cutting machine with 2000w fiber laser source. Cutting pipe & tube of round, square, rectangular, oval, waist round metal, etc. Standard Φ=20mm~200mm, L=6m. Pipes length longer than 6m and diameter more than 200mm, machine can be customized. Model number: P2060 / P2070 / P3080 Laser source: IPG / nLIGHT / Raycus laser generator Laser power: 2000w Pipe length: 6m Pipe diameter: 20mm-200mm / 20mm-300mm Cnc controller: Germany PA Nesting software: Spain Lantek Applicable materials : Metal pipes Max cutting thicknees: 16mm carbon steel, 8mm stainless steel, 6mm aluminum,6mm brass, 4mm copper, 6mm galvanized steel etc. Applicable tube types : Round tube, square tube, rectangular tube, oval tube, D-shaped steel etc. Applicable Industry: sports equipment, display shelf, fitness equipment, playground Equipment, tubes processing industry etc. Golden Laser P series fiber laser tube cutting machine P2060 with the fiber laser generator 2000w can cut the round tube, square tube, rectangle tube, waist round tube, oval tube and other irregulared tubes etc. Tube standard processing diameter 20mm-200mm, tube length 6m. And the customaztion of the tube laser machines is acceptable according to customers' requirement.
