Magnetic separator SEK-P

cascadeliquidsparticle

The robust cascade shaped housing forces the product to closely pass 3 plate magnets. Because these are placed outside the product channel, the pipe channel is unobstructed. In this way, high capacities can be processed, and a high separation efficiency is achieved. Cascade magnets - also called magnetic humps or hump magnets - filter ferrous contaminants from 0.5 to 50 mm from free falling coarse product flows, and are cleaned automatically. Application examples: bulk, animal feed, plastics, ceramics and recycling industries. Capacity up to 300 m³/h Capture Fe particles from 0.5 mm Max. particle size 50 mm ATEX II 1/2 D Automatic cleaning (discontinuous) For coarse, high capacity material flows Cascade magnets filter ferrous contaminants - such as iron and steel - out of granulates, fibres and coarser product flows in high capacity free-fall pipelines. They are often used in the bulk, animal feed, plastics, ceramic and recycling industries, among others.
