Utilization of organic biomaterial (corpses of animals, birds, laboratory material, medical waste,
slaughterhouse waste, etc.) at a temperature of 850 ° C, which allows reliably destroying organic
matter (including those infected with pathogens of dangerous diseases)
1. Automatic loading device
Compared to analogues, the greenex eco waste loading system excludes the ingress of flue gases and flames outside.
2. Primary chamber
Waste incineration process takes place on concrete grates.
The complex is equipped with an ejection system.
The chamber is equipped with a combined multi-layer lining.
3. Liquid-fuel burners
The primary chamber is equipped with two rows of burners, which provide efficient incineration of waste.
4. Secondary chamber
Incineration of toxic gaseous products at temperatures up to 1200 ° C.
5. Ejection fan
Provides vacuum in the primary chamber and cooling of flue gases.
6. Chimney
7. Ash removal module
Ash, falling onto the stoker floor ("Living bottom"), is transferred to a screw conveyor, which unloads it into a specialized container.
8. Fuel tank
The complex is equipped with a programmable logic controller PLC).
Management is carried out by one person
