Truck-mounted crane TLS 60 14
towerfor constructionlifting

Truck-mounted crane - TLS 60 14 - Gruas Saez - tower / for construction / lifting

Truck-mounted crane - TLS 60 14 - Gruas Saez - tower / for construction / lifting - image - 2

Truck-mounted crane - TLS 60 14 - Gruas Saez - tower / for construction / lifting - image - 3

Truck-mounted crane - TLS 60 14 - Gruas Saez - tower / for construction / lifting - image - 4

Truck-mounted crane - TLS 60 14 - Gruas Saez - tower / for construction / lifting - image - 5

Truck-mounted crane - TLS 60 14 - Gruas Saez - tower / for construction / lifting - image - 6

Add to favorites

Compare this product

Characteristics

Configuration

truck-mounted

Structure

tower

Operating environment

for construction

Applications

lifting, loading, handling

Lift capacity

Max.: 6,000 kg
(13,227.7 lb)

Min.: 1,200 kg
(2,645.5 lb)

Max load at max radius

1,430 kg
(3,153 lb)

Horizontal reach

Max.: 60 m
(196'10" )

Min.: 10 m
(32'09" )

Hoisting speed at max load

11 m/min, 37 m/min, 75 m/min

Crane engine power

24 kW
(32.6 hp)

Swing speed

0.3 rpm, 0.6 rpm, 0.9 rpm
(1.885 rad.min-1, 3.77 rad.min-1, 5.655 rad.min-1)

Total counterweight

11,250 kg, 12,500 kg, 14,000 kg, 15,250 kg, 16,750 kg
(24,802.004 lb, 27,557.783 lb, 30,864.717 lb, 33,620.495 lb, 36,927.429 lb)

Description

The Saez TLS 60-14 was the natural progression from the TLS 55-13 and 55-17 models. The concept was to manufacture a CITY crane with a 60m jib. The TLS 60-14 enjoys a unique position in the city-crane division, and is a “world’s first” with these characteristics. The 60-14 is also manufactured with a 1.20m slew, so it can be mounted on S12 mast simply by selecting the “TLS 55-13 load curve” option on the cabin digital display. This innovative crane concept guarantees maximum profitability, and increases the percentage usage of the crane. Its versatility wins it a lot of work, and great returns. The TLS 60-14 incorporates the same cutting-edge technology that we see throughout the TLS and SLH range, including a “prohibited zone system” fitted as standard, and “remote assistance” for any troubleshooting. 100% of the component parts are compatible with the TLS 55-13 and TLS 55-17, and 75% of these parts are compatible with the TLS 60B 8T and TLS 65B 10T. This model has proved to be a very shrewd investment for crane rental companies worldwide.
